Valve Regulated Lead Acid Battery
Specification
Nominal Voltage Nominal Capacity Weight Maximum Discharge Current Internal Resistance Short Circuit Current Maximum Charge Current Terminal types Terminal breaking Torque Container Material | 12V (6 cells per unit) 24W @15min-rate to 1.67V per cell @25°C (77°F) Approx. 1.95 Kg (4.30 Ibs) 100/130A (5sec) Approx. 20.6 mΩ 260A 2.4A F1/F2 Faston Tab187/250 ABS (UL 94-HB) & Flame Retardant (94-V0) available upon request |
---|
Dimensions
Length (L) Width (W) Container Height (h) Overall Height (H) | 151.0±2.0 mm 51.0±1.0 mm 94.3±1.0 mm 98.8±1.0 mm | 5.94±0.08 inch 2.01±0.04 inch 3.71±0.04 inch 3.89±0.04 inch |
---|
