Valve Regulated Lead Acid Battery
Specification
Nominal Voltage Nominal Capacity Weight Maximum Discharge Current Internal Resistance Short Circuit Current Maximum Charge Current Terminal types Terminal breaking Torque Container Material | 12V (6 cells per unit) 94Ah @20hr-rate to 1.75V per cell @25°C (77°F) Approx. 29.70 Kg (65.46 Ibs) 800A (5sec) Approx. 3.6 mΩ 2098A 26.40A l2 thread lead alloy terminal to accept M6 bolt 138.6 Kgf·cm / 120.3 lbf·in / 13.58 N·m PP (UL 94-HB) & Flame Retardant (94-V0) available upon request |
---|
Dimensions
Length (L) Width (W) Container Height (h) Overall Height (H) | 308.7±2.5 mm 169.0±2.0 mm 210.6±2.5 mm 213.6±2.5 mm | 12.15±0.10 inch 6.65±0.08 inch 8.29±0.10 inch 8.41±0.10 inch |
---|
