Performance Characteristics
Nominal Voltage Number of cell Design Life Nominal Capacity 77°F (25°C) 20 hour rate (0.39A, 10.8V) 10 hour rate (0.73A, 10.5V) 5 hour rate (1.30A, 10.5V) 1 hour rate (4.74A, 9.6V) Internal Resistance Fully Charged battery 77°F (25°C) Self-Discharge 3% of capacity declined per month at 25°C (average) Operating Temperature Range Discharge Charge Storage Max. Discharge Current 77°F (25°C) Short Circuit Current Charge Methods: Constant Voltage Charge 77°F (25°C) Cycle use Maximum charging current Temperature compensation Standby use Temperature compensation | 12V 6 5 years
7.8Ah 7.39Ah 6.50Ah 4.74Ah 25mOhms -20~60°C -10~60°C -20~60°C 115A(5s) 390A 14.4-14.8V 3.0A -30mV/°C 13.5-13.8V -20mV/°C |
---|
General Features
Dimensions and Weight
Length(mm / inch) Width(mm / inch) Height(mm / inch) Total Height(mm / inch) Approx. Weight(Kg / Ibs) | 151 / 5.94 65 / 2.56 94 / 3.70 100 / 3.94 2.3 / 5.07 |
---|
