Performance Characteristics
Nominal Voltage Number of cell Design Life Nominal Capacity 77°F (25°C) 20 hour rate (0.6A, 5.25V) 10 hour rate (1.15A, 5.25V) 5 hour rate (2.02A, 5.25V) 1 hour rate (7.8A, 4.8V) Internal Resistance Fully Charged battery 77°F (25°C) Self-Discharge 3% of capacity declined per month at 25°C (average) Operating Temperature Range Discharge Charge Storage Max. Discharge Current 77°F (25°C) Short Circuit Current Charge Methods: Constant Voltage Charge 77°F (25°C) Cycle use Maximum charging current Temperature compensation Standby use Temperature compensation | 6V 3 5 years
12Ah 11.5Ah 10.1Ah 7.8Ah 10mOhms -20~60°C -10~60°C -20~60°C 180A(5s) 600A 7.2-7.4V 4.8A -15mV/°C 6.75-6.9V -20mV/°C |
---|
General Features
Dimensions and Weight
Length(mm / inch) Width(mm / inch) Height(mm / inch) Total Height(mm / inch) Approx. Weight(Kg / Ibs) | 151 / 6.94 50 / 1.97 94 / 3.70 100 / 3.94 1.85 / 4.08 |
---|
