Performance Characteristics
Nominal Voltage Number of cell Design Life Nominal Capacity 77°F (25°C) 20 hour rate (1.30A, 10.5V) 10 hour rate (2.58A, 10.5V) 5 hour rate (4.9A, 10.5V) 1 hour rate (18.4A, 9.6V) Internal Resistance Fully Charged battery 77°F (25°C) Self-Discharge 3% of capacity declined per month at 25°C (average) Operating Temperature Range Discharge Charge Storage Max. Discharge Current 77°F (25°C) Short Circuit Current Charge Methods: Constant Voltage Charge 77°F (25°C) Cycle use Maximum charging current Temperature compensation Standby use Temperature compensation | 12V 6 5 years
26Ah 25.8Ah 24.5Ah 18.4Ah 12mOhms -20~60°C -10~60°C -20~60°C 300A(5s) 1300A 14.4-14.8V 9.6A -30mV/°C 13.5-13.8V -20mV/°C |
---|
General Features
Dimensions and Weight
Length(mm / inch) Width(mm / inch) Height(mm / inch) Total Height(mm / inch) Approx. Weight(Kg / Ibs) | 166 / 6.54 175 / 6.89 125 / 4.92 125 / 4.92 7.6 / 16.75 |
---|
