Performance Characteristics
Nominal Voltage Number of cell Design Life Nominal Capacity 77°F (25°C) 20 hour rate (0.6A, 10.5V) 10 hour rate (1.14A, 10.5V) 5 hour rate (2.05A, 10.5V) 1 hour rate (8.14A, 9.6V) Internal Resistance Fully Charged battery 77°F (25°C) Self-Discharge 3% of capacity declined per month at 25°C (average) Operating Temperature Range Discharge Charge Storage Max. Discharge Current 77°F (25°C) Short Circuit Current Charge Methods: Constant Voltage Charge 77°F (25°C) Cycle use Maximum charging current Temperature compensation Standby use Temperature compensation | 12V 6 5 years
12Ah 11.4Ah 10.25Ah 8.14Ah 19mOhms -20~60°C -10~60°C -20~60°C 180A(5s) 600A 14.4-14.8V 4.8A -30mV/°C 13.5-13.8V -20mV/°C |
---|
General Features
Dimensions and Weight
Length(mm / inch) Width(mm / inch) Height(mm / inch) Total Height(mm / inch) Approx. Weight(Kg / Ibs) | 151 / 5.94 98 / 3.86 95 / 3.74 101 / 3.98 3.67 / 8.10 |
---|
