Performance Characteristics
Nominal Voltage Number of cell Design Life Nominal Capacity 77°F (25°C) 10 hour rate (20A, 10.8V) 5 hour rate (34A, 10.2V) 1 hour rate (120A, 9.6V) Internal Resistance Fully Charged battery 77°F (25°C) Self-Discharge 3% of capacity declined per month at 25°C (average) Operating Temperature Range Discharge Charge Storage Max. Discharge Current 77°F (25°C) Short Circuit Current Charge Methods: Constant Voltage Charge 77°F (25°C) Cycle use Maximum charging current Temperature compensation Standby use Temperature compensation | 12V 6 8-10 years
200Ah 170Ah 120Ah 3mOhms -20~60°C -10~60°C -20~60°C 1600A(5s) 3300A 14.4-14.8V 60A -30mV/°C 13.5-13.8V -20mV/°C |
---|
General Features
Dimensions and Weight
Length(mm / inch) Width(mm / inch) Height(mm / inch) Total Height(mm / inch) Approx. Weight(Kg / Ibs) | 522 / 20.55 238 / 9.37 219 / 8.62 224 / 8.82 66.5 / 146 |
---|
