Performance Characteristics
Nominal Voltage Number of cell Design Life Nominal Capacity 77°F (25°C) 20 hour rate (2A, 10.5V) 10 hour rate (3.8A, 10.5V) 5 hour rate (6.8A, 10.2V) 1 hour rate (40A, 9.6V) Internal Resistance Fully Charged battery 77°F (25°C) Self-Discharge 3% of capacity declined per month at 25°C (average) Operating Temperature Range Discharge Charge Storage Max. Discharge Current 77°F (25°C) Short Circuit Current Charge Methods: Constant Voltage Charge 77°F (25°C) Cycle use Maximum charging current Temperature compensation Standby use Temperature compensation | 12V 6 3-5 years 40Ah 38Ah 34Ah 21.33Ah 8.5mOhms -20~60°C -10~60°C -20~60°C 480A(5s) 540A 14.4-14.8V 10.8A -30mV/°C 13.5-13.8V -20mV/°C |
---|
General Features
Dimensions and Weight
Length(mm / inch) Width(mm / inch) Height(mm / inch) Total Height(mm / inch) Approx. Weight(Kg / Ibs) | 199 / 7.83 166 / 6.54 171 / 6.73 171 / 6.73 12.6 / 27.7 |
---|
