DeNA 6FM36

Voltage (V) : 12 Capacity 20hr (Ah): 36 Dimensions : 197 x 131 x 159 mm (L x W x H)

รายละเอียดสินค้า

Performance Characteristics

Nominal Voltage

Number of cell

Design Life

Nominal Capacity 77°F (25°C)

20 hour rate (1.8A, 10.5V)

10 hour rate (3.42A, 10.5V)

5 hour rate (6.12A, 10.2V)

1 hour rate (36A, 9.6V)

Internal Resistance

Fully Charged battery 77°F (25°C)

Self-Discharge

3% of capacity declined per month at 25°C (average)

Operating Temperature Range

Discharge

Charge

Storage

Max. Discharge Current 77°F (25°C)

Short Circuit Current

Charge Methods: Constant Voltage Charge 77°F (25°C)

Cycle use

Maximum charging current

Temperature compensation

Standby use

Temperature compensation

12V

6

3-5 years



36Ah

34.2Ah

30.6Ah

20.4Ah



8mOhms







-20~60°C

-10~60°C

-20~60°C

960A(5s)

540A



14.4-14.8V

10.8A

-30mV/°C

13.5-13.8V

-20mV/°C

General Features

  • Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99% and freedom from electrolyte maintenance or water adding.
  • Positive and negative plates in lead-calcium-tin alloy
  • Stable quality & high reliability
  • Sealed construction
  • Maintenance-free operation
  • Low pressure venting system
  • Low self discharge
  • High rate discharge
  • Valve Regulated Lead Acid (VRLA) battery
  • V0 Class Flame-Retardant ABS (UL94V-0) container and cover is optional
  • Six months shelf life at 25°C
  • Design life 8-10 years depend on temperature, float charging*

Dimensions and Weight

Length(mm / inch)

Width(mm / inch)

Height(mm / inch)

Total Height(mm / inch)

Approx. Weight(Kg / Ibs)

197 / 7.76

131 / 5.16

159 / 6.26

170 / 6.69

10.7 / 23.54
