Main applications
• Utility Metering
• Automatic meter reading
• Alarms and security devices
• Tollgate systems
• Memory back-up
• Tracking systems
• Automotive electronics
• Professional electronics
Specification
Electrical characteristics (typical values relative to cells stored for one year or less at + 30°C max.)
Nominal capacity (at 3 mA + 20°C 2.0 V cut-off. The capacity restored by the cell varies according to current drain, temperature and cut-off). |
2.1 Ah
|
Open circuit voltage (at +20°C) Nominal voltage (at 0.2 mA +20°C) Nominal energy | 3.67 V 3.6 V 9.36 Wh |
Pulse capability: Typically up to 120 mA (120 mA/0.1 second pulses, drained every 2 mm at +20°C from undischarged cells with 10 µA base current, yield voltage readings above 3.0 V. The readings may vary according to the pulse characteristics, the temperature, and the cells previous history. Fitting the cell with a capacitor may be recommended in severe conditions. Consult Saft) | |
Maximum recommended continuous current (Higher currents possible, consult Saft) Storage (recommended) (for more severe conditions, consult Saft) Operating temperature range (Operation above ambient T may lead to reduced capacity and lower voltage readings at the beginning of pulses. Consult Saft)
Physical characteristics Typical weight Li metal content Available termination suffix CNR, CNR OP 2 PF, 3 PF, 3 PF RP CNA (AX)
Dimensions Diameter Height | 25mA
+30°C (+86°F) max
-60°C / +85°C (-76°F / +185°F)
14.4 g (0.5 oz) approx. 0.6 g
rectangular radial tabs radial pins axial leads
16.5 mm (0.65 in) 33.4 mm (1.31 in) |
