Typical Application
- Utility Metering
- Internet of Things
- Tracking systems
- Alarms and security
- Connected sensors
- Medical devices
Specification
| Electrical characteristics | |
| Nominal capacity (under 1 mA, +20°C, 2.0 V cut-off) | 1.2 Ah |
| Open circuit voltage (at +20°C) | 3.67 V |
| Nominal voltage (under 0.1 mA, +20°C) | 3.6 V |
| Nominal energy | 4.32 Wh |
| Pulse capability | Up to 100 mA |
| Maximum recommended continuous current | 35 mA |
| Operating conditions | |
| Operating temperature range | -60°C / +85°C (-76°F / +185°F) |
| Storage temperature (max recommended) | +30°C (+86°F) |
| Physical characteristics | |
| Typical weight | 9 g (0.31 oz) |
| Li metal content | approx. 0.3 g |
| Termination suffix | |
| CN, CNR | Radial tabs |
| 2PE, 3 PF, 3 PF RP, 4 PF | Radial pins |
| CNA | Axial leads |
| FL | Flying leads |
| Other configurations upon request | |
| Dimensions | |
| Diameter | 14.62 mm (0.57 in) |
| Height | 25.13 mm (0.99 in) |
